Product Description
L-Type Handle, Non-Threaded Detent Pin
●Product Introduction
The L-Type Handle, Non-Threaded Detent Pin is a manually operated component designed for rapid positioning and locking. It features a unique "push-and-turn" mechanism for quick extension and retraction of the plunger, enabling precise location and separation between two components in equipment or jigs and fixtures. Its key characteristic is the omission of traditional threaded mounting, utilizing instead a smooth shank body secured by a spring-and-ball mechanism. This design allows for exceptionally easy and fast installation and removal. The ergonomic L-type handle provides excellent leverage and a comfortable grip, making it ideally suited for applications requiring frequent and rapid position changes or status locking.
●Structural Features
Rapid Operation, Enhanced Efficiency: A simple "push and rotate" action achieves locking and release, significantly increasing operational speed and productivity compared to traditional threaded locking pins.
Non-Threaded Design, Easy Installation: The smooth cylindrical shank requires only a plain bore for installation, eliminating the need for tapped holes. This simplifies the installation process and reduces manufacturing costs.
Self-Alignment and Precise Positioning: The plunger tip typically features a lead-in chamfer, which automatically compensates for minor misalignment, ensuring smooth entry into the locating hole and high repeatability positioning.
Secure and Reliable, Prevents Accidental Release: In the locked position, an internal mechanism (e.g., a ball bearing engaging in a groove) provides a positive mechanical lock, effectively resisting vibration and shock to prevent accidental disengagement.
Ergonomic L-Type Handle: The L-shaped handle offers superior leverage for easy operation. It is often knurled or coated for an anti-slip, comfortable grip, even when wearing gloves.
Maintenance-Free Design: The core internal components, comprising a high-strength spring and precision ball bearing, are robust and long-lasting, requiring no additional lubrication.
●Typical Applications
This product is widely used across various industries due to its speed, convenience, and reliability:
Jigs and Fixtures: For positioning and locking in quick-change machining, welding, and inspection fixtures.
Automation Equipment: In robot end-effector tool changers, positioning for conveyor stations, and rapid mold change systems.
CNC Machinery: For safety interlocking on machine guard doors, positioning for tool magazine doors, and indexing table positioning.
Industrial Machinery: As a safety pin for equipment setup and maintenance, or for securing and limiting the travel of moving parts.
Electronics & Semiconductor Equipment: For precise positioning and rapid locking on frequently opened modules or chambers.
Medical Device Equipment: For accurate positioning and quick disassembly of movable modules.
●Summary
The L-Type Handle, Non-Threaded Detent Pin is the ideal choice for modern industries seeking efficiency, convenience, and reliability. It simplifies complex positioning and locking tasks into a single, effortless motion, making it a key component for enhancing equipment automation and operational ergonomics
